20Cr Steel CV Joint Tripod Heavy Duty AAR CV Joint Inner Tripod

Basic Information
Place of Origin: china
Brand Name: protech CV
Certification: TS16949
Model Number: T08-3422
Minimum Order Quantity: 200
Price: $1-$5
Packaging Details: paper box 5*20*20
Delivery Time: 30 days
Payment Terms: FOB
Supply Ability: 100000
Detail Information
Material: 55# Or 20CrMnTi Steel, High Quality Heat-treatment Design: 100% Match OE Sample , General Design To Make Axle Simple
Technology 1#: Cold Forging Joint Housing Technology 2#: Joint All Grinding, Check Each Tripod To Make It 100% Match Inner Joint
Boot: TPEE Boot Can Resist Lowest Temperature -40 ℃, And Highest Temperature 160 ℃ Clamp: Heavy Duty Clamp, OE Steel
Customized Service: Provide Modified Car And Race Car Customization Services Process: Factory Whole Industry Process, Better Quality Control
HD Axle: EXTREME Weather Unit Axle
High Light:

20Cr steel CV Joint Tripod

,

heavy duty CV Joint Tripod

,

AAR CV Joint Inner Tripod


Product Description

the low plunging resistance and low axial forces of the AAR.Tripod deliver additional NVH refinement, making it appropriate for high working angles. It has a maximum articulation angle of 26 degrees. use carburizing Heat treatment technology, the depth of hardness 0.8-1.2mm, hardness of surface 58-62 HRC,  the heart of tripod hardness 34-44 HRC,  flatness limited 0.04mm,  the perpendicularity tolerance of splines limited 0.04mm.
Good quality of stangth.

20Cr Steel CV Joint Tripod  Heavy Duty AAR CV Joint Inner Tripod 020Cr Steel CV Joint Tripod  Heavy Duty AAR CV Joint Inner Tripod 120Cr Steel CV Joint Tripod  Heavy Duty AAR CV Joint Inner Tripod 2
